Complete description of the selected organ
Photo: Janco Schout
Warffum, Nederland (Groningen) - Sebastiaankerk
Municipal: Het Hogeland
Region:Hunsingo
Address: Hoofdstraat 18, 9989 AN, Warffum
Description nr.: 1001798.
Groningen Orgelland number: 180. De Mixtuur card number: A20.
Built by: Heinrich Hermann Freytag and Johannes Wilhelmus Timpe (1812)
Technical data
Specification
Hoofdwerk (C-f'''): Bourdon 16', Prestant 8', Baarpijp 8', Holpijp 8', Octaaf 4', Speelfluit 4', Quint 3', Octaaf 2', Cornet IV sterk (8') (discant) - 1985, Mixtuur III-V sterk (1 3/5') (B/D), Trompet 8' - 2003, Dulciaan 8'.
Bovenwerk (C-f'''): Roerfluit 8', Fluit Travers 8' (discant), Prestant 4', Fluit 4', Quintfluit 3' - 2023, Woudfluit 2' - 2023, Carillon III sterk (4') (discant), Vox Humana 8' - 2023, Tremulant.
Pedaal (C-d'): Subbas 16' - 1932, Octaafbas 8' - 1932, Gedekte Bas 8' - 1932, Bazuin 16' - 1932.
Couplers: Manuaalkoppel, Pedaal - Hoofdwerk.
Accessories: Tremulant (hele orgel), 2 Ventielen.
Other sources
Photo: Janco Schout
Warffum, Nederland (Groningen) - Sebastiaankerk
Municipal: Het Hogeland
Region:Hunsingo
Address: Hoofdstraat 18, 9989 AN, Warffum
Description nr.: 1001798.
Groningen Orgelland number: 180. De Mixtuur card number: A20.
Built by: Heinrich Hermann Freytag and Johannes Wilhelmus Timpe (1812)
| Year | Builder | Opus | Activity | 1812 | Heinrich Hermann Freytag | new organ | 1895 | Petrus van Oeckelen | restoration | 1932 | firma M. Spiering | restoration and enlargement | 1987 | Orgelmakerij Reil | restoration | 2023 | Orgelmakerij Reil | restoration |
- The organ in the Sebastiaankerk (Protestant Church) in Warffum was built by Heinrich Hermann Freytag. After his death in 1811, his pupil Timpe completed the organ. The instrument had two manuals with 20 stops and attached pedal. Mr. M. Walles constructed the wood carving of the organ case together with his son.
- The firm Van Oeckelen & Zonen repaired the organ in 1895 and modified its disposition. They replaced the Trumpet 8' with a new one, and installed a Violoncel, a Gamba and a Clarinet on the Bovenwerk. For this, the Nasard 2 2/3', the Woudfluit 2' and the Vox Humana were sacrificed. In 1932, the company Spiering installed an independent pneumatic pedal with four stops and they converted the Gamba from Van Oeckelen into a Vox Celeste.
- In 1987 the Gebroeders Reil company restored the organ. The stop list of the Hoofdwerk was reconstructed, and a new pedalboard was also made. The Clarinet from 1895 was removed in 2004, with the intention of reconstructing the Vox Humana at this location. This stop was used in the restoration of the Van Oeckelen organ in the Lutherse Kerk in Groningen.
- In 2020 a new restoration was started by Reil, under consultancy of Stef Tuinstra. The purpose was to rebuild the organ entirely in its initial state. The pedal organ that had been added in 1931-1932 by Spiering has been preserved. The instrument could be inaugurated on July 7, 2023. Stef Tuinstra presented the organ, after which a concert was played by Gerben Budding.
Technical data
| Number of stops per division | |
| - Hoofdwerk | 12 |
| - Bovenwerk | 8 |
| - Pedaal | 4 |
| Total number of stops | 24 |
| Key action | Mechanical |
| Stop action | Mechanical |
| Windchest(s) | Slider chests |
| Pitch | 1/4 toon boven normaal |
| Temperament | Young 1800 |
| Wind pressure | 67 mm (Manualen), 76 mm (Pedaal) |
Specification
Hoofdwerk (C-f'''): Bourdon 16', Prestant 8', Baarpijp 8', Holpijp 8', Octaaf 4', Speelfluit 4', Quint 3', Octaaf 2', Cornet IV sterk (8') (discant) - 1985, Mixtuur III-V sterk (1 3/5') (B/D), Trompet 8' - 2003, Dulciaan 8'.
Bovenwerk (C-f'''): Roerfluit 8', Fluit Travers 8' (discant), Prestant 4', Fluit 4', Quintfluit 3' - 2023, Woudfluit 2' - 2023, Carillon III sterk (4') (discant), Vox Humana 8' - 2023, Tremulant.
Pedaal (C-d'): Subbas 16' - 1932, Octaafbas 8' - 1932, Gedekte Bas 8' - 1932, Bazuin 16' - 1932.
Couplers: Manuaalkoppel, Pedaal - Hoofdwerk.
Accessories: Tremulant (hele orgel), 2 Ventielen.
| Compound stop | Composition |
| Cornet IV sterk discant (Hoofdwerk) | c': 8' - 4' - 2 2/3' - 1 3/5'. |
| Mixtuur III-V sterk (Hoofdwerk) | C: 1 3/5' - 1 1/3' - 1'. c°: 2' - 1 3/5' - 1 1/3' - 1'. c': 2 2/3' - 2' - 1 3/5' - 1 1/3' - 1 1/3'. c'': 4' - 3 1/5' - 2 2/3' - 2' - 2'. |
| Carillon III sterk discant (Bovenwerk) | c': 4' - 1 3/5' - 1'. |
| Other specifications | |
|---|---|
| Different specifications |
Before 2023, the stop list was: Hoofdwerk (C-f'''): Bourdon 16', Prestant 8', Baarpijp 8', Holpijp 8', Octaaf 4', Spitsfluit 4', Quint 3', Octaaf 2', Cornet IV sterk (discant) - 1985, Mixtuur III-V sterk (B/D), Trompet 8' - 1895, Dulciaan 8', Tremulant - 1932. Bovenwerk (C-f'''): Fluit Travers 8' (discant), Roerfluit 8', Violoncel 8', Vox Celeste 8' - 1895/1932, Prestant 4', Fluit 4', Carillon III sterk (discant), Clarinet 8' - 1895; removed in 2004, Tremulant. Pedaal (C-d'): Subbas 16' - 1932, Octaafbas 8' - 1932, Gedekte Bas 8' - 1932, Bazuin 16' - 1932. Koppelingen: Manuaalkoppel. |
| Literature |
|
| Recordings |
Freytag-orgel Sebastiaankerk Warffum / Jan Harryvan. - SGO-2024-C1 (CD). - 2024. |
| Links |
https://www.orgelshogeland.nl/?page_id=23 https://reil.nl/orgels/sebastiaankerk/ http://www.petertenkate.nl/Warffum.htm https://www.rtvnoord.nl/nieuws/719375/Monnikenwerk-in-een-kerk-orgel-van-Warffum-wordt-gerestaureerd |
