Description complète d'orgue sélectionné
Photo: Tjalling Roosjen
Schaffhausen, Die Schweiz / La Suisse (Schaffhausen) - Katholische Pfarrkirche Sankta Maria
Commune: Schaffhausen
Adresse: Promenadenstrasse 23, 8200, Schaffhausen
Site Web: https://www.kathschaffhausen.ch/
Description no.: 2030020.
Bâti par: Johann Nepomuk Kuhn (1883) - opus 52
In 1883 Johann Nepomuk Kuhn built an organ for the Schweizerische Landesausstellung in Zurich. It is a two-manual organ with mechanical action and cone chests. In 1885 the instrument was installed in the Sankta-Mariakirche in Schaffhausen. The Kuhn company restored the work in 1975-1976, after which it was put back into use on March 23, 1976.
Court sommaire des endroits où l'orgue s'est trouvé
Données techniques
Composition
Hauptwerk (C-f'''): Bourdon 16', Principal 8', Gamba 8', Gedeckt 8', Flauto Dolce 8', Salicional 8', Octav 4', Fugara 4', Octav 2', Cornett 4 fach (8'), Mixtur 4 fach (2 2/3'), Trompete 8'.
Schwellwerk (C-f'''): Bourdon 16', Geigenprincipal 8', Lieblich Gedeckt 8', Wienerflöte 8', Viola 8', Aeoline 8', Voix Céleste 8' (from c°), Geigenprincipal 4', Traversflöte 4', Clarinette 8', Tremolo.
Pedal (C-d'): Principalbass 16', Violonbaß 16', Subbaß 16', Octavbaß 8', Violoncello 8', Posaune 16', Trompete 8'.
Accouplements: Manual Coplung, Coplung Pedal zum I. Manual, Coplung Pedal zum II. Manual.
Photo: Tjalling Roosjen
Schaffhausen, Die Schweiz / La Suisse (Schaffhausen) - Katholische Pfarrkirche Sankta Maria
Commune: Schaffhausen
Adresse: Promenadenstrasse 23, 8200, Schaffhausen
Site Web: https://www.kathschaffhausen.ch/
Description no.: 2030020.
Bâti par: Johann Nepomuk Kuhn (1883) - opus 52
Année | Facteur | Opus | Activité | 1883 | Johann Nepomuk Kuhn | 52 | orgue neuf | 1885 | Johann Nepomuk Kuhn | transfer | 1976 | Orgelbau Kuhn AG | restauration |
In 1883 Johann Nepomuk Kuhn built an organ for the Schweizerische Landesausstellung in Zurich. It is a two-manual organ with mechanical action and cone chests. In 1885 the instrument was installed in the Sankta-Mariakirche in Schaffhausen. The Kuhn company restored the work in 1975-1976, after which it was put back into use on March 23, 1976.
Court sommaire des endroits où l'orgue s'est trouvé
1883 | Zürich | Schweizerische Landesausstellung |
1885 | Schaffhausen | Sankta-Mariakirche |
Données techniques
Nombre de registres par manuel | |
- Hauptwerk | 12 |
- Schwellwerk | 10 |
- Pedal | 7 |
Nombre de jeux total | 29 |
Transmission des clés | Mechanical |
Transmission des jeux | Mechanical |
Sommier(s) | Cone chests |
Composition
Hauptwerk (C-f'''): Bourdon 16', Principal 8', Gamba 8', Gedeckt 8', Flauto Dolce 8', Salicional 8', Octav 4', Fugara 4', Octav 2', Cornett 4 fach (8'), Mixtur 4 fach (2 2/3'), Trompete 8'.
Schwellwerk (C-f'''): Bourdon 16', Geigenprincipal 8', Lieblich Gedeckt 8', Wienerflöte 8', Viola 8', Aeoline 8', Voix Céleste 8' (from c°), Geigenprincipal 4', Traversflöte 4', Clarinette 8', Tremolo.
Pedal (C-d'): Principalbass 16', Violonbaß 16', Subbaß 16', Octavbaß 8', Violoncello 8', Posaune 16', Trompete 8'.
Accouplements: Manual Coplung, Coplung Pedal zum I. Manual, Coplung Pedal zum II. Manual.
Autres données des dispositions | |
---|---|
Autres dispositions |
De oorspronkelijke dispositie uit 1883 luidde: I. Manual: Bourdon 16', Prinzipal 8', Flauto Dolce 8', Gamba 8', Gedeckt 8', Salicional 8', Octav 4', Fugara 4', Octav 2', Cornett 5 fach (8'), Mixtur 4 fach (2 2/3'), Trompete 8'. II. Manual: Lieblich Gedeckt 16', Geigen-Prinzipal 8', Lieblich Gedeckt 8', Viola 8', Wiener Flöte 8', Aeoline 8', Voix Céleste 8', Geigen-Prinzipal 4', Travers Flöte 4', Clarinette 8'. Pedal: Prinzipalbass 16', Subbass 16', Violon 16', Octavbass 8', Violon Cello 8', Posaune 16', Trompete 8'. Koppelingen: I. Manual - II. Manual, Pedal - I. Manual, Pedal - II. Manual. Speelhulpen: 5 Collectivzüge. |
Références |
Die Schweizerische Landesausstelung in Zürich, 1883 / Oscar Laffert. - In: Zeitschrift für Instrumentenbau, 3. Band, No. 25, 1. Juni 1883. |
Lièns |
https://www.orgelbau.ch/op=800360 https://www.sh-orgel.ch/orgeln |
